GPRO® QM40 Series
The GPRO QM40 Mechanical Fuel Meter provides precision fuel measurements for more accurate readings for fleet operations, heavy equipment, and agricultural applications. It features a magnetic drive mechanism that is nearly frictionless; less friction results in more flow, capable of handling flow rates up to 40 GPM. The QM40 is equipped with both NPT and Flange connections which allows it to be installed on all threaded pump outlets or modular GPI products.
For ground-based refueling only. Do not use or mount in or on the aircraft. For use with aviation gasoline (Avgas 100LL), Jet A, and Jet A-1 . User should consult NFPA 407 Standard for Aircraft Fuel Servicing for safety requirements during ground fuel servicing of aircraft using liquid petroleum fuels. This product has no actual or implied compliance with this standard. Owners and operators are responsible for compliance to all applicable regulations.
Specification
Manuals / Documents
| Max. Flow Rate: | 2 – 40 GPM (8-150 L/min) |
| Accuracy (% of Reading): | +/- 1/2% across flow range from 2-40 GPM (8-150 L/min) |
| Technology: | Oval Gear |
| Max. Discharge Pressure: | 50 PSI (3.45 bar) |
| Operating Temperature: | -40° F to 125° (-40° C to 52° C) |
| Connection Type/Size: | Modular with NPT (Female) Adapter, 1-inch |
| Meter Housing Material: | Corrosion-Resistant Aluminum |
| Wetted Materials: | Acetal | Aluminum | NBR | Neodymium | PPS | Stainless Steel |
