Petroleum Flow Meters

Turbine Flow Meter, Pulse Out, 4-20mA, Stainless Steel Body for Petro Chem, Water, and Solvents

Flomec
Get a Quote

FLOMEC® G2 Series - MODEL G2S-05-N-42

The FLOMEC G2 Stainless Steel series with integrated pulse / 4-20 mA output offers a robust design for metering more demanding liquid flow, withstanding high-pressure and high-temperature applications. The factory 5-point calibration process ensures accuracy of reading across the flow range.

Brand: . Category: .

Recommended for use with these fuels:

Solvents | Water | Petroleum-based Chemicals

Features & Benefits

  • Features highly visible Q9, LCD display

  • The 4-20mA Module with integrated display provides an industry-standard analog signal for connection to a variety of chart recorders, display equipment, and process control equipment

  • 11 pre-programmed engineering units plus 1 custom option: gallon, litre, imperial gallon, quart, ounce, acre-foot, millilitre, cubic foot, cubic centimetre, cubic metre, barrel

  • High accuracy meter – view SPECIFICATIONS of each SKU once meter options are selected

  • Internal parts are simple to replace for easy maintenance

  • NPT, ISO 7, #150 ANSI Flange, and Tri-clamp fitting options

  • Tri-clamp (not food grade) options available: ¾-inch fitting for ½-inch pipe, 1-inch fitting for ¾-inch pipe, 1-½-inch fitting for 1-inch pipe, 2-inch fitting for 1-½-inch pipe, 2-½-inch fitting for 2-inch pipe

  • Specification
  • Manuals / Documents
Max. Flow Rate:1 – 10 GPM (3.8-38 L/min)
Accuracy (% of Reading):+/- 1.5%
Technology:Turbine
Pressure Rating:1500 PSI (103 bar)
Operating Temperature:-40° F to +185° F (-40° C to +85° C)
Connection Type/Size:NPT (Female), 1/2-inch
Pipe Size:1/2-inch
Meter Housing Material:Stainless Steel
Wetted Materials:316 Stainless Steel | Ceramic | PVDF | Tungsten Carbide
